Hoses and Couplings
Hoses
We offer Rubber hoses along with Corrugated SS Flexible Hoses, PTFE (smooth) & (convoluted) bore flexible hose, Thermoplastic Composite Hose, Cryogenic hose along with Dry break coupling and break away coupling.
We can also offer rig and production hoses such as Rotary and vibrator hoses (API 7k), Choke and Kill hoses (API 16C), BOP hoses and Production hoses (API 17k).
We supply wide range of hoses and hose fittings ranging from 5 mm to 400 mm dia. And with a pressure range up to 20,000 psi working pressure.
Standards
EN 13765: Type 3, BS 3492-BX and BS 5842
Service Applications
Covers a large range of service applications from:
- Oil – Crude, lube oil, white oil, black oil, and edible oil.
- Chemicals including HCL, sulphuric acid, acetic acid, phosphoric acid, ethyl mercaptan, caustic, and all other A B C class chemicals.
- Cryogenics such as LPG & Ammonia.
Size Range
- 1 inch to 12-inch ID.
- Temperature Range: -45°C to 120°C
Features
- Single continuous length up to 24 meters without welding.
- No rubber or welding in the hoses; hence no chances of cracking, aging, or kinking.
- Extremely lightweight.
- Composite hoses are resistant to salty seawater and perfect for rugged offshore and onshore applications.
Couplings
Dry Break or Dry Disconnect Coupling is an internationally preferred hose connection device that provides an automatic mechanism to seal off both the hose and the fixed pipe end when the hose is disconnected.
In coupling, we offer Quick, dry break, and breakaway coupling.
Technical Specifications
- Sizes: 1" (DN19 - DN32) to 6" (DN150).
- MOC: MS, CS, Brass, SS 304, SS 316, SS316L, Aluminium, gunmetal, and stainless steel 316L. Other materials available on request.
- Pressure: Up to 4000 psi.
- Temperature: -25ºC to 250ºC
- Seals: FKM (Viton®), NBR (Nitrile), EPDM, Chemraz®, Kalrez®. Other materials available on request.
- Working pressure: 10-25 bar
- Test pressure: Working pressure +50%
- Safety factor: 5:1
- End connections: BSP- and NPT-threads. DIN-, ASA-, TW- and TTMA-flanges (available for both coupler and adaptor). Other threads and flanges available on request.
- Compatibility: NATO STANAG 3756.
- Application: LPG, Lube plant, Off shore application, Chemical and POL application.
